3GHD-OE-SFP Single Optical to Electrical Media Converter

Order no: 24041

The Flashlink 3GHD-OE-SFP is an SFP based multi bit-rate optical to electrical converter module.

It provides high performance media conversion supporting 3G-, HD- and SD-SDI signal formats in addition to DVB-ASI, SMPTE310M and MADI. The modular design with the ability to quickly replace a whole unit with its optical modules attached makes the 3GHD-OE-SFP the first choice for mission critical applications.

The converter is utilizing SFP receivers that are pluggable devices, enabling easy exchange or upgrade of optical ports and minimizing spare stock. High quality SFP based optical PIN and APD receivers makes the product suitable for short and medium/ long haul applications. The standards compliance of Nevion Flashlink products also allows for easy inter-operability with third party fiber optical systems.

The units optical converter features a dual electrical outputs, which reduces the need for additional distribution amplifiers.

3GHD-OE-SFP complements the extensive range of Flashlink optical transport products covering video, audio and data signals, strengthening Flashlink reputation as the number one optical transport platform for broadcasters and network operators.

Benefits:

  • High reliability
  • World class optical range
Applications:
  • Dark fiber networks
  • Optical video transport
  • Broadcast contribution networks
Key Features:
  • Single optical input
  • Dual electrical output
  • up to -30dBm optical sensitivity
  • 3G/HD/SD-SDI and DVB-ASI reclocker
  • Temperature measurement

order no. 24041

SFPs are ordered separately.

APPLICABLE OPTICAL VIDEO SFPs:



Item numberItem NameDescription long
24157SFP-3G-OE-LSingle channel optical long haul receiver SFP supporting data rates up to 3Gbps including SD, HD and 3G-SDI. These devices are designed to be compatible to pathological video signals.
24156SFP-3G-OESingle channel optical receiver SFP supporting data rates up to 3Gbps including SD, HD and 3G-SDI. These devices are designed to be compatible to pathological video signals.

  3GHD-OE-SFP
