Nevion Products

ADA-IP-MUX Analog and digital audio over IP multiplexer

Categories: Product Family: Flashlink Application Area: Broadcast Infrastructure, IP Production Networks Functionality: IP adaptation Media Interface: Analog audio, Digital audio (AES) Technology: AES67, PTP, Uncompressed Audio Transport interface: IP/Ethernet

The ADA-IP-MUX is an analog and digital audio over IP product used for audio networking in broadcast applications.

The analogue audio conversion is broadcast quality, providing a dynamic range above 105dBA for any conversion. The digital audio signals may be transported completely bit transparent. This ensures optimized audio quality for both analog and digital audio signals.

The product provide routing of audio in the IP layer, and together with its digital version AES-IP-MUX, several of these products can be used together as a large distributed mixed analog and digital audio router. The product also supports bi-directional audio transport making it well suited  for both AES and 4-wire based intercom transport.

Its multiplex design is optimized for ensuring low and fixed latency in the audio network.

The board can be ordered with 4 stereo pair inputs, 4 stereo pair outputs or 2 stereo pair inputs + 2 stereo pair outputs.

The card is easy to use with minimum setup needed and broadcast centric control enabled thru Nevions control panel support.

Benefits:

  • Enabling remote production
  • Can be deployed on LANs

Applications:

  • Live media networking
  • Audio networking
  • Intercom transport

Key Features:

  • Supporting network topologies
  • Fully bit transparent audio transport of all channels
  • 4 analog stereo pair ports
  • 8 AES ports (direction follows analog audio option)
  • AES67 compliant stream
  • PTP support
  • Supported only by Flashlink FR202 chassis and Flashcase II

  ADA-IP-MUX DS

24121 ADA-IP-MUX

Mark the order with information about analog audio option:

  • ADDA: 2 stereo inputs, 2 stereo outputs
  • DAC: 4 stereo outputs
  • ADC: 4 stereo inputs

  AES.ADA-IP-MUX user manual Rev.A
