Nevion Products

ADC-AES-8 Quad stereo audio to AES converter

Order no: 21284

Categories: Functionality: Signal conversion Product Family: Flashlink

The Flashlink ADC-AES-8 is a quad stereo audio converter with 4 stereo A/D converters located on a single module. The module may be used as a stand-alone module well suited for high density modular audio conversion or stand-alone applications with the one slot N-box.

It may also be used as an auxiliary module to the AV-3G-XMUX on a dedicated connector panel. With the second generation FlashCase this option only occupies one module slot. Also available in this family are the ADDA-AES-8 and DAC-AES-8.

Benefits

  • High integration level
  • High audio quality
  • easy configuration

Applications

  • Audio conversion application
  • Studio infrastructure

Key Features

  • 8 analog audio inputs (4 stereo)
  • External AES11 reference input
  • 4 AES outputs
  • 107dB(A) dynamic range A/D conversion
  • 48 or 96kHz sampling frequency
  • Manually controlled gain settings
