ARC-SD-DMUX – LEGACY - SD-SDI aspect ratio converter with frame sync and analog video/audio outputs

Categories: Product Family: Flashlink Functionality: Format conversion

The Flashlink ARC-SD-DMUX converts the aspect ratio of a SD-SDI signal. The module instantaneously changes the scaling during the vertical blanking period. The module addresses the need to convert between standard 4:3 and widescreen 16:9 formats employed by different digital TV standards. Flexible aspect ratio control is available for either 4:3 or 16:9. The ARC-SD-DMUX has applications in both contribution and distribution networks.

The ARC-SD-DMUX’ small form factor makes the ARC-SD-DMUX ideal for use with SD cameras in an Flashlink single-card N-BOX housing. An analog monitor output is also available for viewing the converted video shots. This makes the card a powerful tool for small-scale productions.

Benefits

  • High integration
  • Nevion phase-tru technology
  • Optical interface

Applications

  • Studio infrastructure
  • Studio interconnection
  • OB production
  • Aspect ratio conversion

Key Features

  •  Aspect ratio converter for SD-SDI with monitor output
  • Automatic and user configurable modes of operation
  • Built-in frame synchronizer with de-glitcher ensures error-free switching
  • Audio de-embedding, processing and cross-point matrix
  • Based on Nevion’s unique PhaseTru scaling technology
  • Active format description support Aspect ratio converter for SD-SDI withmonitor output
  • Automatic and user configurable modes of operation
  • Built-in frame synchronizer with de-glitcherensures error-free switching
  • Audio de-embedding, processing andcross-point matrix
  • Based on Nevion’s unique PhaseTru scalingtechnology
  • Active format description support
  • 2x SDI outputs
  • 3x analog video outputs, supporting CVBS, YCbCr and RGB
  • Analog stereo audio output
  • AES3 output
  • Optical short haul receiver
  • Sync input supporting BB and tri-level

  arc-sd-dmux_ds

LEGACY MODELS:

18726ARC-SD-DMUXSD aspect ratio converter with 2 digital video outputs, 3 analog video outputs, and stereo analog audio.
18727ARC-SD-DMUX-RSD aspect ratio converter with 2 digital video outputs, 3 analog video outputs, and stereo analog audio. With short haul optical receiver.

  arc-sd-dmux
