VS906-AA analog audio transport over IP

Categories: Product Family: Media Gateways, Ventura Functionality: IP adaptation Media Interface: Analog audio, IP/Ethernet access Transport interface: IP/Ethernet Technology: E-aptX, SMPTE 2022-7, Uncompressed Audio Application Area: Contribution Networks
NOTE: This product is a version, a variant or a module of a main product. For further information about this product, visit the main product page.

The VS906-AA is a modular, multichannel analog audio contribution codec for IP/Ethernet networks.

With the VS906-AA users can deploy multiple analog audio circuits in point-to-point local loop applications or over long-distance packetized networks. This flexible platform enables highly cost-efficient analog audio transport and with companion video transport cards, provides a comprehensive media delivery platform for virtually any environment including—long distance, metro area and campus networks.

Applications

  • Professional broadcast contribution
  • Studio-to-studio media exchange
  • Live sports and event contribution
  • Managed data services over IP
  • Radio contribution and distribution networks

Key Features

  • Multichannel audio encapsulation based on EBU – TECH 3326
  • Forward Error Correction based on SMPTE 2022-1
  • Streaming Intelligent Packet Switching (SIPS) providing perfect video over IP protection switching using dual network feeds
  • Encoder partner protection (EPP) for 1+1 hardware redundancy in combination with SIPS
  • Dual Gigabit Ethernet networks interfaces using SFP technology for up to 80km of reach. Gigabit Ethernet or Fast Ethernet electrical network interface option

  Nevion_VS906_AA_data_sheet_R1618

VS906 AA 3.9

  VS906_AA_Release_Notes ()
